Table Overview for Cubic Indoor CO2 sensor

Model	Working Principal	Measurement Range	Accuracy	Communication	Working Current	Recommendations
High Accuracy NDIR CO2 Sensor CM1106H-NS CM1106H-NS	NDIR	UART/I²C:0-10000ppm PWM:0-2000ppm	± (30ppm+3% of reading)	UART,I²C,PWM	<50mA @ 1s	High accuracy, meet RESET grade A & California title 24		Specifications Features Measurement Range UART/I²C:0-10000ppm PWM:0-2000ppm Accuracy ± (30ppm+3% of reading) Communication UART,I²C,PWM Working Current <50mA @ 1s
Super Low Power CO2 Sensor CM1106SL-NS CM1106SL-NS	NDIR	0-5000ppm	± (50ppm+3% of reading)	UART, I²C	<37uA @ 2min	Super low power consumption 37uA@2mins Without PIN Recommended for battery-powered devices		Specifications Features Measurement Range 0-5000ppm Accuracy ± (50ppm+3% of reading) Communication UART, I²C Working Current <37uA @ 2min
Connector Type NDIR CO2 Sensor CM1106S-W CM1106S-W	NDIR	0-5000ppm	± (50ppm+3% of reading)	UART	<20mA @ 1s	Connector type with terminal block for flexible connection		Specifications Features Measurement Range 0-5000ppm Accuracy ± (50ppm+3% of reading) Communication UART Working Current <20mA @ 1s
Single Beam NDIR CO2 Sensor CM1106-C CM1106-C	NDIR	0-5000ppm	± (50ppm+5% of reading)	UART,I²C,PWM	<45mA @ 1s	Single beam NDIR, ABC open by default		Specifications Features Measurement Range 0-5000ppm Accuracy ± (50ppm+5% of reading) Communication UART,I²C,PWM Working Current <45mA @ 1s
Dual Beam NDIR CO2 Sensor CM1107N CM1107N	NDIR	0-5000ppm	± (30ppm+3% of reading)	UART,I²C,PWM	<50mA @ 1s	Dual channel with reference Channel, high accuracy Suitable for the application without fresh air		Specifications Features Measurement Range 0-5000ppm Accuracy ± (30ppm+3% of reading) Communication UART,I²C,PWM Working Current <50mA @ 1s
Dual Beam NDIR CO2 Sensor CM1107NS CM1107NS	NDIR	0-10000ppm	± (30ppm+3% of reading)	UART,I²C,PWM	<50mA @ 1s	Wide measurement range to 10000ppm Dual channel, high accuracy Suitable for the application without fresh air		Specifications Features Measurement Range 0-10000ppm Accuracy ± (30ppm+3% of reading) Communication UART,I²C,PWM Working Current <50mA @ 1s
5% NDIR CO2 Sensor CM1107H CM1107H	NDIR	0-5.00% Vol	± 0.02% Vol+10% of reading	UART,I²C	<50mA @ 1s	Large measurement range to 5% Dual channel, high accuracy Recommend for cellar, brewery, agriculture facilities, industrial plants etc.		Specifications Features Measurement Range 0-5.00% Vol Accuracy ± 0.02% Vol+10% of reading Communication UART,I²C Working Current <50mA @ 1s

Load More

CO2 Sensor

Ultra-Low Power LED CO2 Sensor
CM1108UL

CM1108UL

Cubic CM1108UL is an ultra-low power CO2 sensor developed based on NDIR technology. Adopting ultra-low power LED light source, CM1108UL achieves super low power consumption less than 30μA, making it ideal for battery-powered or energy-constrained applications. Based on NDIR technology, it offers high accuracy ± (40ppm+3% of reading), under a wide measurement range from 400 to 5,000 ppm, meeting the requirements of RESET and WELL standards. Furthermore, with automatic baseline correction mecha...

Learn more

Specifications Features

Operating Principle

NDIR (Non-dispersive Infrared)

Measurement Range

400-5000ppm

Measurement Accuracy

± (40ppm+3% of reading)

Average Working Current

≤30μA
- NDIR technology
- LED light source, super low power consumption
- Long life span (≥ 15 years)
- Compact design, easy for integration
High Accuracy NDIR CO2 Sensor
CM1106HA-NS

CM1106HA-NS

High accuracy with ±75ppm@400-2500ppm to meet newest AHSRAE 62.1-2022 standard for demand control ventilation(DCV) applications, CO2 sensor CM1106HA-NS can be used to detect CO2 concentration of indoor air by adopting advanced non-dispersive infrared technology (NDIR).

Learn more

Specifications Features

Measurement range

PWM: 0-2000ppm
UART/ I²C: 0-10000ppm (Note 1)

Working temperature

-10°C ~ 50°C

Working humidity

0-95%RH (non-condensing)

Storage temperature

-30°C ~ 70°C
- NDIR technology with independent intellectual property
- Temperature calibration within whole measurement range
- Long life span, auto-calibration, maintenance free
- Small size and compact structure, easy to install
High Accuracy NDIR CO2 Sensor
CM1106H-NS

CM1106H-NS

High accuracy with ±（30ppm+3% of reading) CO2 sensor CM1106H-NS can be used to detect CO2 concentration of indoor air by adopting advanced non-dispersive infrared technology (NDIR). With auto-calibration, no need of maintaince. It is widely used in ventilation system, air conditioner, air purifier, IAQ monitor, agriculture, plant cultivation and cold-chain, etc.

Learn more

Specifications Features

Measurement range

PWM: 0-2000ppm
UART/ I²C: 0-10000ppm (Note 1)

Working temperature

-10°C ~ 50°C

Working humidity

0-95%RH (non-condensing)

Storage temperature

-30°C ~ 70°C
- NDIR technology with independent intellectual property
- Temperature calibration within whole measurement range
- Long life span, auto-calibration, maintenance free
- Small size and compact structure, easy to install
Connector Type NDIR CO2 Sensor
CM1106S-W

CM1106S-W

Connection terminals with PIN holes are suitable for special connection methods. CM1106S-W is a single beam NDIR CO2 sensor module, based on non-dispersive infrared (NDIR) technology, which can detect CO2 concentration of indoor air. With high accuracy, high stability, small size, it is widely used for ventilation system, air purifier, air conditioner, HVAC transmitter, IAQ monitor, etc.

Learn more

Specifications Features

Measurement range

0-5000ppm

Response time

≤30s

Accuracy

±(50ppm+3% of reading) @ 0℃-50℃, 50±10%RH (Note 1 and 2)

Working temperature

-10℃~50℃
- NDIR technology with independent intellectual property
- High accuracy, long term stability, long life ( >10years)
- Auto-calibration, no need of maintenance
- Signal output UART/I²C
- Small size and compact structure, easy to install
Super Low Power CO2 Sensor
CM1106SL-N

CM1106SL-N

CM1106SL-N is super low power consumption NDIR CO2 sensor with PIN type, widely used for battery powered applications. Single measurement mode and continuous measurement mode for choose. Widely used for air quality monitor, HVAC controller. Etc.

Learn more

Specifications Features

Measurement range

0-5000ppm

Accuracy

± (50ppm+5% of reading) (Note 1)
± (50ppm+3% of reading) (Note 2)

Working humidity

0~95%RH（non-condensing)

Working current

74uA (1 minute as measurement cycle)
37uA (2 minutes as measurement cycle, default in the sensor)
- NDIR technology with independent intellectual property
- Super low power consumption
- High accuracy, long-term stability, long life (>15 years)
- Temperature calibration within whole measurement range
- Auto-calibration, no need of maintenance
- Small size and compact structure, easy to install
- Wide supply voltage range enables variety of battery options
- Adjustable measurement cycle by host
- ABC setting by host
Super Low Power CO2 Sensor
CM1106SL-NS

CM1106SL-NS

CM1106SL-NS is super low power consumption NDIR CO2 sensor without PIN type, widely used for battery powered applications. Single measurement mode and continuous measurement mode for choose. Widely used for air quality monitor, HVAC controller. Etc..

Learn more

Specifications Features

Measurement range

0~5000ppm

Accuracy

± (50ppm+5% of reading) (Note 1)
± (50ppm+3% of reading) (Note 2)

Working temperature

-10℃~50℃

Working humidity

0~95%RH（non-condensing)
- NDIR technology with independent intellectual property
- Super low power consumption
- Pin holes connection for flexible connection
- UART and I2C communication available
- Long-term stability, long lifespan (>15 years)
- Temperature calibration within whole measurement range
- Auto-calibration, no need of maintenance
- Small size and compact structure, easy to install
- Wide supply voltage range enables variety of battery options
- Adjustable measurement cycle by host
- ABC setting by host
Single Beam NDIR CO2 Sensor
CM1106-C

CM1106-C

CM1106-C series is a single beam NDIR CO2 sensor, based on non-dispersive infrared (NDIR) technology with independent intellectual property, which can detect CO2 concentration of indoor air. With auto-calibration, no need of maintaince. With high accuracy, long term stability, small size, it is widely used for ventilation system, air purifier, air conditioner, HVAC transmitter, IAQ monitor, etc.

Learn more

Specifications Features

Measurement range

0-5000ppm

Response time

≤30s

Accuracy

±(50ppm+5% of reading) @0℃~50℃, 50±10%RH

Working temperature

-10℃~50℃
- NDIR technology with independent intellectual property
- High accuracy, long term stability, long lifespan (>10 years)
- Temperature calibration within whole measurement range
- Auto-calibration, no need of maintenance
- Signal output PWM/UART/I²C
- Small size and compact structure, easy to install
Low Power NDIR CO2 Sensor
CM1106LS

CM1106LS

Low power with working current 35mA, CM1106LS is a single beam NDIR CO2 sensor module, based on non-dispersive infrared (NDIR) technology, which can detect CO2 concentration of indoor air. With ABC open by default, and no need of maintaince. With high accuracy, high stability, small size, it is widely used for ventilation system, air purifier, air conditioner, HVAC transmitter, IAQ monitor, etc.

Learn more

Specifications Features

Measurement range

400-5000ppm

Response time

≤30s

Accuracy

±(50ppm+3% of reading) @0℃~50℃, 50±10%RH (Note 1 and 2)

Working temperature

-10℃~50℃
- NDIR technology with independent intellectual property
- High accuracy, long term stability, long lifespan (>10 years)
- Temperature calibration within whole measurement range
- Auto-calibration, no need of maintenance
- Signal output PWM/UART/I²C
- Small size and compact structure, easy to install
Dual Beam NDIR CO2 Sensor
CM1107N

CM1107N

CM1107N is a dual beam (single light source, dual channel) CO2 sensor, based on non-dispersive infrared (NDIR) technology, which can detect CO2 concentration of indoor air. With higher accuracy, superior long term stability, it is widely used for ventilation system, air purifier, air conditioner, intelligent agriculture, storage and cold-chain, etc

Learn more

Specifications Features

Measurement range

0~5000ppm default

Response time

≤30s

Accuracy

±(30ppm+3% of reading) @0℃~50℃, 50±10%RH

Working temperature

-10℃~50℃
- NDIR technology with independent intellectual property
- Dual beam detection for superior stability and better accuracy
- High accuracy, long term stability, long life (>10years)
- Temperature calibration within whole measurement range
- Signal output PWM/UART/ I²C
- Small size and compact structure, easy to install
Dual Beam NDIR CO2 Sensor
CM1107NS

CM1107NS

CM1107NS is a dual beam (single light source, dual channel) CO2 sensor with wider measurement range(0-10000ppm) , based on non-dispersive infrared (NDIR) technology, which can detect CO 2 concentration of indoor air. With higher accuracy, superior long term stability. It is widely used for ventilation system, air purifier, air conditioner, intelligent agriculture, storage and cold-chain, etc

Learn more

Specifications Features

Measurement range

0~10000ppm default

Response time

≤30s

Accuracy

±(30ppm+3% of reading) (0℃~50℃, 0-5000ppm, 50±10%RH)

Working temperature

-10℃~50℃
- NDIR technology with independent intellectual property
- Dual beam detection for superior stability and better accuracy
- High accuracy, long term stability, long lifespan (>10years)
- Wide range measurement range 0-10000ppm
- Temperature calibration within whole measurement range
- Signal output PWM/UART/I 2 C
- Small size and compact structure, easy to install
5% NDIR CO2 Sensor
CM1107H

CM1107H

CM1107H is base on dual beam platform with measurement range 0-5.00% Vol. It is with idea sensing solution for control- and alarm applications. It can be integrated into a wide range of different CO2 alarm applications that are critical in ensuring safety such as cellar, brewery, agriculture facilities, industrial plants, ,and dry ice storage, code chain, and is also can be used for ventilation system, air purifier, air conditioner, ect.

Learn more

Specifications Features

Measurement range

0-5.000% Vol

Resolution

0.001% Vol

Working temperature

-10°C ~ 50°C

Working humidity

0-95%RH (non-condensing)
- NDIR technology with independent intellectual property
- Dual beam detection for superior stability and better accuracy
- High accuracy, long term stability, long life (>10years)
- Temperature calibration within whole measurement range
- Signal output UART/I2C
- Small size and compact structure, easy to install
Dual IR Sources NDIR CO2 Sensor
CM1109

CM1109

Cubic patented two-engine CO2 sensor CM1109 is used to detect CO2 concentration of indoor air by adopting infrared (NDIR) technology. With higher accuracy and better stability, it is widely used for ventilation system, air purifier, air conditioner, intelligent agriculture, storage and cold-chain, etc.

Learn more

Specifications Features

Measurement range

400-5000ppm

Response time

≤30s

Accuracy

±(50ppm+3% of reading) @0℃~50℃, 50±10%RH

Working temperature

-10℃~50℃
- Dual IR source NDIR technology with independent intellectual property
- High accuracy, long term stability, long lifespan(＞15 years)
- Matrix calibration within whole measurement range and temperature range
- Small size and compact structure, easy to install
- Signal output PWM/UART/ I²C

Load More
