Integrated Sensor Module

Integrated Air Quality Sensor Module
AM1008W

AM1008W

Integrated sensor solutions for indoor application, Cubic provide all in one sensor combined CO2 sensor, particle sensor , VOC and RH&T sensor to keep building healthy.

Learn more

Specifications Features

Measurement range

CO2: 0~5000ppm; PM: 0~1000μg/m³; VOC: 0~3level;

Temperature

-20℃~70℃; RH:0%~95%RH

PM accuracy

PM2.5: 0~35μg/m³, ±5μg/m³ >35μg/m³, ±15% of reading (Condition: 0℃~40℃, 50±10%RH Reference instrument: TSI Dust Source: Cigarette + Arizona A1)

CO2 accuracy

±(50ppm+5% of reading) (0~2000ppm, 0~50℃, 50±10%RH)
- 4 in 1 sensor module which integrated particle, CO2, VOC and RH&T
- PM1.0 PM2.5 and PM10 output simultaneously
- Auto-calibration NDIR CO2 sensor
- Precise accuracy and robust performance
- With voltage regulator design and EMC compliant, strong anti-static ability
- Ultra-thin structure
Integrated Air Quality Sensor Module
AM1002

AM1002

Integrated sensor solutions for indoor application, Cubic provide all in one sensor combined particle sensor , VOC and RH&T sensor to keep building healthy.

Learn more

Specifications Features

Measurement range

Particle: 0~5000μg/m³
VOC: 0~10ppm
Temperature: -20℃~70℃
Humidity: 0~99%RH

PM accuracy

PM1.0/PM2.5: 0~100μg/m³ : ±10μg/m³ , 101~500μg/m³ : ±10% of reading
PM10: 0~100μg/m³ : ±25μg/m³ ,101~500μg/m³: ±25% of reading
(GRIMM, 25±2℃, 50 ±10%RH)

VOC consistency

Typical/Max: 200ppb/250ppb OR 20%/25%, whichever is larger

Temperature accuracy

0°C ~ 40°C: ±1°C
- 4 in 1 sensor module which integrated particle, VOC and RH&T.
- Real time PM1.0 PM2.5 and PM10 output simultaneously.
- High accuracy, high sensitive and quick response.
- Temperature compensation algorithm.
- Matrix calibration technology and optimized algorithm, for high accuracy and consistency.
- Long lifespan and high stability.
- Small size, compact structure, easy to install.
Integrated Air Quality Sensor Module
AM1009

AM1009

Integrated sensor solutions for indoor application, Cubic provide all in one sensor combined particle sensor, VOC&NO2 sensor and R&H sensor to keep building healthy.

Learn more

Specifications Features

Measurement range

PM: 0~5000μg/m³; VOC: 0~10ppm; NO2: 0-1000ppb

Temperature

-20℃~70℃

RH

0%~95%RH

PM accuracy

PM1.0/PM2.5: 0~100μg/m³: ±10μg/m³; 100~500μg/m³: ±10% of reading
PM10: 0~100μg/m³: ±20μg/m³; >100μg/m³: ±20% of reading
25℃±2℃, 50±10%RH, GRIMM, Cigarette+Arizona A1)
- 5 in 1 sensor module which integrated particle, VOC NO2 and RH&T
- Real time PM1.0 PM2.5 and PM10 output simultaneously
- High accuracy, high sensitive and quick response
- Temperature compensation algorithm
- Matrix calibration technology and optimized algorithm, for high accuracy and consistency
- Long lifespan and high stability
